Weight Stack
-
Units have fully shrouded weight stacks in full compliance with ASTM and EN standards.
-
Each selector plate is entirely precision-machined on all surfaces. Top plate has replaceable precision self-lubricating bushings.
-
The plates feature a black-painted protective finish. Guide rods are precision centerless ground, polished, with corrosion-resistant plating for smooth operation and rust retardation.
-
The weight stack is elevated to facilitate user pin selection from the seated position.
Upholstery
-
Premium-quality 3D urethane molded foam padding for maximum comfort. Fabric meets or exceeds California fire regulations (Bulletin 117, section E). Automotive-grade, two-textured fabric features double top stitching on all seams.
Instructional Placard
-
Easy-to-understand exercise placards feature large set-up and start and finish position diagrams that are visibly easy to identify. QR codes provide quick and easy video instruction from your smartphone or Preva app.
Bearings and Pivot Points
-
Oversized, linear, re-circulating ball bearings run on case-hardened shafts and are sealed and self-aligning. Pivot points and joints feature motor-grade sealed ball bearings or sleeve bearings, utilizing either oil-impregnated bronze bushings or pre-lubricated nylon bushings. Bolts are grade 5 or above in all applications.
Pulleys and Cables
-
Glass-fiber-reinforced nylon pulleys for durability, with precision motor-grade ball-bearing pulleys. Cable consists of 3/16 inch (7"x19") aircraft cable coated with black pressure-extruded nylon to 1/4 inch or 1/8 inch and coated to 3/16 inch. The cables conform to specification MIL-W-83420D-BARE cable only. When used, redirection pulleys route cables close to frame to minimize chance of external interference.
Frame and Finish
-
The frame is made of 11 gauge (.120 in) 2x4" electrowelded steel racetrack tubing. The movement arms are made of electrowelded steel round tubing. The five-stage material prep/wash process is followed by an electrostatically applied, heat-cured powder coat.
General Features
-
Dual independent-movement arms feature upper pivots to accommodate arm lengths and can be set to 13 starting positions over a 120-degree range. The weight stack is offset to the user's right for the most convenient access.
Equipment Specifications
-
Incremental Add-on Weight: 5 lbs (2.3 kg)
-
Weight Stack: 240 lbs (109 kg)
Tech Specs
-
Dimensions (L x W x H): 54" x 56" x 84" (137cm x 142cm x 213cm)
-
Equipment Weight: 594 lbs (269 kg)
-
Shipping Weight: 655 lbs (297 kg)
